CDD-562AL/564A/L Multi-Channel Demodulator Revision 0
Ethernet-based Remote Product Management MN-CDD562AL564AL
7–2
• Compatible web browser, such as Internet Explorer
7.3 SNMP Interface
The Simple Network Management Protocol (SNMP) is an Internet-standard protocol for managing
devices on IP networks. An SNMP-managed network consists of three key components:
• Managed device
• SNMP agent
• Network Management System (NMS)
7.3.1 Managed device
This includes the CDD-56xA/L Multi-Channel Demodulator.
7.3.2 SNMP Agent
This is the software that runs on the CDD-56xA/L. The CDD-56xA/L SNMP Agent supports both
SNMPv1 and SNMPv2c.
7.3.3 User-supplied Network Management System (NMS)
This is the software that runs on the manager.
7.3.4 Management Information Base (MIB) Files
MIB files are used for SNMP remote management of a unique device. These MIB files must be compiled
in a user-supplied MIB Browser, or compiled on an SNMP Network Monitoring System server.
A MIB file consists of a tree of nodes called Object Identifiers (OIDs). Each OID provides remote
management of a particular function.
7.3.4.1 FW-0020899*.mib, MIB file
CDD-564A MIB file consists of all of the OIDs for management of the demodulators functions.
7.3.4.2 FW-0020903*.mib, Traps MIB file
CDD-564A Traps MIB file is provided for SNMPv1 traps.
