PCB-4000 1+1 Phase Combiner Revision 2

Appendix A MN/PCB4000.IOM

A–14

A.3.1.2 X-Band 1:1 Waveguide and Switch Redundant Assembly Kit – ODPA (KT/11387-1)

Table A-7. Kit KT/11387-1 BOM

Kit KT/11387-1 (see Figure A-6)

Item No. QTY CEFD Part No. Description

3 1 RF/CG-112/137INN Cross guide Coupler, 40 dB, Type N Connector, 137-112

4 1 FP/WG11671-1 Waveguide, 1:1 Filter to TX

5 2 SW/WG-HAGS

Switch, WR112G, +24V, Sealed, Standard Thread, Cold Temperature

Rating

7 2 FP/WG11305-1 Waveguide, 90 Degree H-Bend Transition

8 2 FP/WG11301-1 Waveguide, 90 Degree, CPRG-112

9 3 FP/WG11308-1 Waveguide, 90 Degree, H-Bend, CPRG-112

11 1 RF/X-TERM850W Termination, Load, 850 Watt, CPRG112, with Cross guide Coupler, 40 dB

13 14 GA/CPR112-R-F-C Gasket, Round, CPR112, Full Thickness,

20 A/R HW/8-32HEXNUT Nut, Hex 8-32

21 A/R HW/8-FLT Washer, Flat SS

22 A/R HW/8-SPLIT Washer, Split SS

23 A/R HW/8-32X1/2SHCS Screw, Socket Cap

24 A/R HW/8-32X7/8SHCS Screw, Socket Head Cap, SS

25 A/R HW/SEM632X3/8PH Screw, Square Cone Pan Head Phillips SS

31 1 RF/ADAP-112-N Adapter, CPRG112 to "N"

32 1 RF/CG-112/137INN Coupler, Cross guide 40 dB N Type Connector

55 4 RF/N-TERM50M1

RF, 50Ω 1Watt, DC-8 GHz, Type N Male

Note:A/R=AsRequired
