PCB-4000 1+1 Phase Combiner Revision 2

Appendix A MN/PCB4000.IOM

A–4

A.2 Common Kit Subassemblies

A.2.1 Universal Pole Mounting Kit (PL/12319-1)

Table A-2. Kit PL/12319-1 BOM

PL/12319-1 Universal Pole Mounting Kit (as per Figure A-1 on next page)

Item

No.

QTY CEFD Part No. Description

1 N/A (FP-0000134)

Unistrut, Dual Channel (SHOWN FOR CLARITY ONLY, P/O CEFD KT-0000017 MOUNTING KIT)

2 1 FP/BR0072

Bracket, Strap Tensioner

3 1 FP/BR0070

Bracket, Strap Termination

4 1 FP/BR0071

Bracket, 1-1/4 Strap (TRIM TO REQUIRED LENGTH)

5 1 FP/BR0069

Bracket, Strap, Fixed

6 2 HW/M8X1.25X25HEXSS

Bolt, Hex head, M8X1.25X25, SS

7 7 HW/M8FLATSS

Washer, Flat, M8, SS, METRIC

8 7 HW/M8LOCKSS

Washer, Split Lock, M8, SS, METRIC

9 2 HW/M8SPRINGNUT

Spring Nut, M8X1.25

10 5 HW/M8X1.25MMHEXNUTSS

Nut, Hex M8X1.25X16MM, SS

11 2 HW/PIPEBLOCK

Pipe Block


