PCB-4000 1+1 Phase Combiner Revision 2

Updating Firmware MN/PCB4000.IOM

4–5

o Finally,fromtheCommand‐line‘c:\>’prompt,type“mkdirtemp”or“mdtemp”

(mkdirandmdstandformakedirectory),andthenclick[OK].



Thereshouldnowbea"temp"foldercreatedandavailableforplacementofthe

firmwarefiledownload.

4.3 Downloading and Extracting the

Firmware Update

1. First,downloadthefirmwareupdatefilefromtheComtechEFDataWebsite:



A. Goonlinetowww.comtechefdata.com

.



B. OntheMain page–underSupportInformationortheSupporttab,selecttheSoftware

Downloadshyperlink.



C. OntheSoftwareDownloadspage–clickDownloadFlashandSoftwareUpdateFiles.



D. On the Flash Updates Index page – select the (Select a Product Line) Transceivers

hyperlink.



E. Under the MBT‐4000/B heading, select the PCB4

000 (1+1 Phase Combiner) product

hyperlink.



F. SelecttheappropriatefirmwarearchiveEXEorZIPfiledownloadhyperlink.



• About Firmware Numbers, File Versions, and Formats:The Comtech EF

DataWebsitecatalogues itsfirmwareupdate filesbyproduct type(e.g.,

router, modem, etc.), the specific model, and optional hardware

configurations.



Thedownloadhyperlink for the PCB‐4000baseunitfirmware appears as

FW11411‐1x.CCC,where‘x’denotestherevisionlette

r.



• AboutFileArchiveFormats:Comtech EFDataprovidesitsdownloadable

filesin twocompressedarchive formats: *.exe(self‐extracting ) and*.zip

(compressed).



The *.exe file does not require a file archiver and compression utility
