PCB-4000 1+1 Phase Combiner Revision 2

Updating Firmware MN/PCB4000.IOM

4–10



If the upload is not successful for any

reason (e.g., the comms cable is not

physically connected, the wrong COM

port is specified, the user

inadvertently interru pted the upload,

etc.), troubleshoot the setup as

needed, and then click on ‘Rep eat

Upload’ or ‘Go Back to Start’ to

resumeorretrytheuploadprocess.

8. Uponsuccess

fulcompletionoftheupload,youmayclick

on ‘Go Back to Start’ (if, for example, more than one

PCB‐4000 1+1 Phase Combined System requires 

upgrade)or‘Close’(toexit theFLSHCATprogram).



9. Ifneeded,disconnecttheSystemProgramming

Cable (CEFD P/N CA/WR12243‐1) and

reconne

ct the original System Communications

connectioncable.



10. The LEDs on the top of the PCCB may illuminate GREEN

(unmuted), ORANGE (muted), or RED (faulted) to indicat e

thecurrentstatusofthePCCB,SSPA1,andSSPA2oper ations.

See Chapter 3. INSTALLATION, STARTUP, and

TROUBLE

SHOOTINGPROCEDURESformoreinformationon

theseope rati onalstates.



ThePCB‐4000FirmwareUpdateProcessisnowcomplete.
