PCB-4000 1+1 Phase Combiner Revision 2

Appendix A MN/PCB4000.IOM

A–10

A.3 PCB-4000 1+1 Phase Combiner Box Assemblies

ThePCB‐40001+1PhaseCombinerstandaloneunitisavailableinanX‐Band,C‐Band,orKu‐Bandversion.ThePCCBmaybeavailableasa

topassemblylineitemorasakitsubassemblyitem(FigureA‐4).



For example, the standalone PL/11285‐1 X‐Band unit isprovided as part ofthe top‐level KT/11344‐1 X‐Band systemassembly kit. It is

alsoprovidedasasubassemblyiteminaboxandbracke

tkitwhichis,inturn,alineitemprovidedinthetop‐levelKT‐0000055C‐Band

orKT‐0020623Ku‐Bandsystemassemblykits.



Table A-5. PCB-4000 1

+1 Phase Combiner Box Kit BOM

Item

No.

Box and Bracket Kit / QTY

CEFD Part No. Description

KT-0000056 KT-0020622

N/A N/A PL/11285-1 1+1 Phase Combiner Box, X-Band

1 – PL-0000030 1+1 Phase Combiner Box, C-Band

– 1 PL-0021051 1+1 Phase Combiner Box, Ku-Band

2 1 1 FP-0020874 Bracket, Mounting, Phase Combiner Box

3 4 4 HW/10-FLT Washer, Flat, 3/8, SS

4 4 4 HW/10-SPLIT Washer, Lock, Split, 3/8, SS

5 4 4 HW10-32x1/2SH Bolt, Socket Head, SS

6 2 2 HW-0000070 Screw, Hex, Serrated Flange Head, SS

7 2 2 HW3/8SPRINGNUT Spring Nut, 3/8-16, Short Spring, SS (P3300)




