PCB-4000 1+1 Phase Combiner Revision 2
Installation, Startup, and Troubleshooting Procedures MN/PCB4000.IOM
3–7
3.4 Gain or Amplitude Balance Verification and Alignment
ThisprocedureisgenerallynotnecessaryifallparametersofSection3.3have
beenmet.
As a result of the configuration of the waveguide switches in a 1+1 system, it is possible to
measuretheindividualgainofeachSSPApathbyswitchingeachSSPAindividuallytotheoutput
load.
Thisprocedu
reassumesthattheoutputportisterminatedandthatdatawillbetakenusingthe
CombinedOutputPowerandWastedPowerTestCouplers(
Figure 3-1).
Followthesesteps:
Step Task
1
A. Attach a power meter to the Combined Output Power Test Coupler (Figure 3-1).
B. Apply a low-level signal at center frequency, making sure the output signal will be at least 10 dB below
Prated.
2
To measure only the individual gain of SSPA#1, SSPA#2 must by bypassed by changing the state of the
waveguide switches via remote control (for detailed remote command and query information, see Chapter
5. SERIAL REMOTE CONTROL):
A. Execute remote command RED=0;
B. Execute remote command BYP=2.
The output of SSPA#1 will be sent to the system output, while SSPA#2 will be muted and directed to the
“wasted” port.
3 Record the amplitude or gain level of SSPA#1.
4
Execute remote command BYP=1 to measure the individual gain of SSPA#2. This time, the output of
SSPA#2 will be sent to the system output, while SSPA#1 will be muted and directed to the “wasted” port.
5 Record the amplitude or gain level of SSPA#2.
6
Compare the levels of the two paths. Typically, the gains of each SSPA will be within ± 1 dB at center
frequency. If the above test is performed at other frequencies, it is reasonable to assume that the gain
difference may be greater.
