SDM-2020 Satellite Demodulator Revision 4

Fully Accessible System Topology (FAST) MN/SDM2020D.IOM

4–3

7. Use [←] and [→] select CARD #2 (Reed-Solomon Card) menu.

8. Record Card #2 serial number, if displayed:

9. Press [CLEAR].

10. Contact a Comtech EF Data sales representative to order features.

11. Comtech EF Data Customer Support personnel will verify the order and

provide an invoice and instructions.

Entering Access Codes from the Front Panel

1. Press CLEAR to return to Main menu.

2. Use the [←] [→] keys to go to the Function Select: Utility menu.

3. Press <ENTER>.

4. Go to Utility: Modem Type menu.

5. Press <ENTER>.

6. Go to Configuration Code-Modem menu.

7. Press <ENTER>.

8. Menu should display as follows:

1) AAAAAAAAAA

2) AAAAAAAAAA

9. To enter the code, press <ENTER> and use the [↑] [↓] keys to select an

alphanumeric character. Use [→] to move to the next character or to move to

the next line. Repeat this procedure until all 20 characters of the code have

been entered.

10. After completing entry of the 20-character code, press <ENTER>. The unit

should display Modem Initialization and will reboot to the factory default

settings with the new option available.

11. If a wrong or invalid code is entered, the unit will display Wrong Code

Entered! and no changes will occur. Please retry the code, verify that the

code is correct, or request assistance from Comtech EF Data Customer

Support.
