SDM-2020 Satellite Demodulator Revision 4
RS-422 Data Interface MN/SDM2020D.IOM
7–6
Table 7-2. DVB Interface Connector Pinout, J3
Pin # Signal Function/Name Type Comment
1 Clock A I/O Mod/Demod
2 System GND/REFCLKB
O/GND Mod/Demod
Jumper selectable
SCT for Modulator
3 Data 7 A(MSB/Serial) I/O Mod/Demod
4 Data 6 A I/O Mod/Demod
5 Data 5 A I/O Mod/Demod
6 Data 4 A I/O Mod/Demod
7 Data 3 A I/O Mod/Demod
8 Data 2 A I/O Mod/Demod
9 Data 1 A I/O Mod/Demod
10 Data 0 A I/O Mod/Demod
11 DVALID A I/O Mod/Demod
12 SYNC A I/O Mod/Demod
13 Cable Shield I/O Mod/Demod
14 Clock B I/O Mod/Demod
15 System GND/REFCLKA
O/GND Mod/Demod
Jumper selectable
SCT for Modulator
16 Data 7 B (MSB/Serial) I/O Mod/Demod
17 Data 6 B I/O Mod/Demod
18 Data 5 B I/O Mod/Demod
19 Data 4 B I/O Mod/Demod
20 Data 3 B I/O Mod/Demod
21 Data 2 B I/O Mod/Demod
22 Data 1 B I/O Mod/Demod
23 Data 0 B I/O Mod/Demod
24 DVALID B I/O Mod/Demod
25 SYNC B I/O Mod/Demod
7.3.1.2 Serial, J4, DB25 Female (EIA-530 Serial Data Interface)
This interface has no provision for SYNC or DVALID signals. If framing is desired, a
sync byte (47 hex) is embedded into the data stream every 188 or 204 bytes, as selected
in the Demodulator configuration.
The Demodulator detects the sync byte and formats the
serial interface data into a standard, error-protected 204-byte packet.
