SDM-2020 Satellite Demodulator Revision 4
Front Panel Operation MN/SDM2020D.IOM
6–40
Displays the current RR STATE, either NORMAL or INVERT.
Upon entry, the current status is displayed. Press [↑] or [↓] to change the
selection. Press <ENTER> to execute the change.
6.1.9.4 Function Select: Utility: Interface: LVDS
INTERFACE TYPE
LVDS
Press <ENTER> to review or edit the following sub-menus.
Function Select: Utility: Interface: LVDS: INTRF Mode Select
INTRF MODE SELECT
SERIAL
Displays the current Interface Mode Select, either SERIAL or Parallel.
Upon entry, the current status is displayed. Press [↑] or [↓] to change the
selection. Press <ENTER> to execute the change.
6.1.9.5 Function Select: Utility: Interface: ASI/RS422
INTERFACE TYPE
ASI/RS422
Press <ENTER> to review or edit the following sub-menus.
Function Select: Utility: Interface: ASI/RS422: Interface Select
INTERFACE SELECT
ASI
