SDM-2020 Satellite Demodulator Revision 4
Front Panel Operation MN/SDM2020D.IOM
6–56
Function Select: Utility: Demod Options: Demod Options
DEMOD OPTIONS
-----
(Status Only)
Displays the following demodulator options:
• OEM LCD
• 8PSK
• 16QAM
• 2 L-Band Inputs
• 4 L-Band Inputs
• 70/140 MHz
Notes:
1. If the option is installed, the “+“ (plus) symbol is displayed to the right of the
option
2. If the option is not installed, but is a FAST upgrade the “-“ (minus) symbol is
displayed to the right of the option.
3. If the option is not installed and not upgradeable, the “0” symbol is displayed to
the right of the option.
4. If the option is not installed, but is field upgradeable, the “X’” symbol is
displayed to the right of the option.
Upon entry, the current status is displayed. Press [↑] or [↓] to change the selection. Press
<ENTER> to execute the change.
Function Select: Utility: Demod Options: Modem Emulation
(Conditional)
MODEM EMULATION
DISABLED
IMPORTANT
For FW/7734-1 only.
Displays the current status DISABLED or EMULATED VERSION.
