SDM-2020 Satellite Demodulator Revision 4
Front Panel Operation MN/SDM2020D.IOM
6–57
Upon entry, the current status is displayed. Press [↑] or [↓] to change the selection. Press
<ENTER> to execute the change.
Function Select: Utility: Demod Options: Demod Serial #
DEMOD SERIAL #
123456789
(Status Only)
Displays the demodulator serial number.
Upon entry, the current status is displayed. Press [↑] or [↓] to change the selection. Press
<ENTER> to execute the change.
Function Select: Utility: Demod Options: Configuration Code
CONFIGURATION
CODE - DEMOD
Comtech EF Data supplied code (FAST).
On entry, the current configuration code is displayed with the flashing cursor on the first
character. Press [←] or [→] to move the flashing cursor. Press [↑] or [↓] to increment or
decrement the digit at the flashing cursor. Press [ENTER] to execute the change.
1) AAAAAAAAAA
2) AAAAAAAAAA
Entering this code enables the corresponding demodulator option. To purchase an option,
contact Comtech EF Data Customer Support for more information.
6.1.12 Function Select: Utility: Factory Set-Up
