DMD2050E Universal Satellite Modem Web Browser Setup Guide
MN-DMD2050E Revision 2 D–16
D.6.4.2 Reset the Ethernet M&C port
To reset the Ethernet M&C port, either 1) cycle the electrical power OFF and ON, or, 2) re-enter
the
Modem IP Address. Re-entering the Modem IP Address avoids traffic disruption.
D.6.4.3 Re-enter the Modem IP address
1. Go to SYSTEM / TCP/IP / MODEM IP ADDR.
2. Press
ENTER.
3. Type the new
IP Address and press ENTER.
4. Press
ENTER again.
5. Retype the new
IP Address and press ENTER.
IMPORTANT
You must change the
IP Address
. If you just press
ENTER
repeatedly without changing
the
IP Address
, the Ethernet M&C port is not reset.
