DMD2050E Universal Satellite Modem Web Browser Setup Guide
MN-DMD2050E Revision 2 D–12
D.6.3 Configure Chrome for the Radyne WEB Browser
When you open the Monitor & Control window, you may see the error message “This webpage is
not available”.
Click the Chrome address bar.
Make sure the full address is highlighted, and then press
Enter. The Monitor & Control window
opens.
On the
Monitor & Control, Password Setup or IP Administration windows, some fields may be
blank or contain
Update.
To correct the display, either 1) change the encoding, or, 2) install the Internet Explorer Tab V2
add-on.
NOTE
If you leave a window and return, it may be necessary to correct the display again.
