OM20 Universal Outdoor Modem Appendix B
MN-OM20– Revision 5 B–6
The Web Browser menu allows viewing of actively enabled features. Each feature displays a
series of symbols that describe feature status. The following symbols indicate:
Installed
No hardware available. Requires
hardware for upgrade.
Feature is in Demo Mode and will
expire.
Key Code Required
Call customer service. Feature is
enabled for customer use, but the
OM20 hardware required has not been
detected or has failed.
Features upgrades can also be implemented through the Web Browser interface.
