OM20 Universal Outdoor Modem Web Browser/Remote Protocol

MN-OM20– Revision 5 6–35

ReedSolomon Control: {ENABLED, DISABLED}

Allows the user to Enable/Disable the Reed-Solomon Encoder.

RS N Value: {Refer to Table 3-1 for valid n/k values}

Displays the currently used N value, Reed-Solomon Codes. In

Closed Net Mode, the user may select custom R-S Codes if

optional Reed Solomon Card is installed.

RS K Value: {Refer to Table 3-1 for valid n/k values}

Displays the currently used K value, Reed-Solomon Codes. In

Closed Net Mode, the user may select custom R-S Codes if

optional Reed Solomon Card is installed.

Rx Interleaver Depth: {4, 8, 12}

ODU-LNB Menu

Figure 6-17. ODU-LNB Menu

LO Frequency (MHz): Allows the user to enter the Local Oscillator frequency in MHz

in order for the downlink frequency to be displayed correctly

(refer to the LNB manufacturer’s specifications).

Osc Side Band: {LOW SIDEBAND, HIGH SIDEBAND}
