Digital Satellite Terminal System Revision 1

Block Up Converter MN/DST.IOM

3–3

3.2 LO, Mix and Spectrum Settings

3.2.1 C-Band

Table 3-1. LO, MIX and Mod Spectrum Settings for Modulator And BUC

P1dB_min

Band

FSK

CEFD Part #

RF Start

Frequency

(GHz)

RF End

Frequency

(GHz)

LO (Offset)

Freq.

(MHz)

Mix

(±)

Modem

Spectrum

(Utility

Modulator

Menu)

Supply

Voltage

Spar

Mount Kit

Feed

Mount Kit

5 Watt C Yes RF/BUC05C-A-F-T 5.850 6.425 7,375.00 - Invert 24 VDC KT/8924-1 KT/9027-1

10 Watt C Yes RF/BUC10C-A-F-T 5.850 6.425 7,375.00 - Invert 48 VDC TBD TBD

1 Watt C No RF/BUC01C-A-N-N 5.850 6.425 4,900.00 + Normal 24 VDC KT/8924-1 KT/9027-1

2 Watt C No RF/BUC02C-A-N-N 5.850 6.425 4,900.00 + Normal 24 VDC KT/8924-1 KT/9027-1

5 Watt C No RF/BUC05C-A-N-N 5.850 6.425 4,900.00 + Normal 24 VDC KT/8924-1 KT/9027-1

2 Watt Ext C No RF/BUC02C-B-N-N 6.725 7.025 5,760.00 + Normal 24 VDC KT/8924-1 KT/9027-1

5 Watt Ext C No RF/BUC05C-B-N-N 6.725 7.025 5,760.00 + Normal 24 VDC KT/8924-1 KT/9027-1
