Digital Satellite Terminal System Revision 2

Installation MN/DST.IOM

2–2

2.2 Equipment Inspection

2.2.1 Included Parts

A typical Satellite Terminal System contains the following components:

Notes:

1. Parts are not drawn to scale.

2. Because each installation can be customized, this manual will provide

instructions for installing the universal mounting kit.

Table 2-1. Mounting Components

Qty Description Qty Description

1 DST Components

2 Cable Assembly – Transmit (Optional)

Comtech EF Data Part No. CA/6357-50, -

100, -150, -175, or -200

1 Installation and Operation Manual

2 Cable Assembly – Receive (Optional)

Comtech EF Data Part No. CA/9645-50, -

100, -150, -175, or -200

1 Envelope containing the test data

1 IDU Mounting Bracket (Optional)

FP/6138-1 From Comtech EF Data Kit

KT/6228-1

1 2 ... 21 22 23 24 25 26 27 28 29 30 31 ... 65 66
