Operation RCF6001 Satellite Terminal

Page 3-4 TM082 Rev. 1.0

C-Band Block Upconverter Specifications

Electrical Performance Parameters

Output frequency range 5.85 – 6.425 GHz

Input frequency range 950 – 1525 MHz

Input level range -5 to –55 dBm (-20 for P1dB)

Reference signal frequency 10 MHz

Reference signal level -3 to +10 dBm

Power levels Available up to 40 watts

Ku-Band Block Upconverter Specifications

Electrical Performance Parameters

Output frequency range 14.0 – 14.4 GHz

13.75 – 14.25 GHz (option)

Input frequency range 950 – 1525 MHz

Input level range -5 to –55 dBm (-20 for P1dB)

Reference signal frequency 10 MHz

Reference signal level -3 to +10 dBm

Power levels Available up to 25 watts

(The following specifications apply to both C- and Ku-Band Bucs)

Intermodulation IM

> -30 dBc

(Two tone signal with 5 MHz distance and a summary output power

of 6 dB below rated power, 6 dB back off)

Gain stability ± 0.5 dB/day at constant temperature

Gain variation (flatness) ± 2 dB over 500 MHz

(over freq. and temp.) ± 1 dB over any 80 MHz band

Group delay < 10 ns over any 80 MHz band

Carriers transmit interrupt > 50 dB

Local oscillator phase noise < 2.8

RMS double sideband

Spurious < -20 dBm (in-band)

Noise figure < 20 dB

DC input 42 to 60 Vdc (nominal 48V)

(24 Vdc optional)
