Front Panel Operation Revision 2
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
6–65
Use the arrow keys to select an alphanumeric character to edit, and then use the
arrow keys to change that character. You may use the following characters:
[Space] ( ) * + - , . / 0-9 and A-Z
Press ENTER once you compose your desired Circuit ID string.
6.2.6.8 (Utility:) Firmware
CAUTION – THESE SUBMENUS ARE INTENDED FOR DIAGNOSTIC PURPOSES ONLY. DO
NOT
CHANGE AN IMAGE UNLESS OTHERWISE DIRECTED BY COMTECH EF DATA
PRODUCT SUPPORT.
These submenus permit you to view information about the CDM-760 internal firmware, or to
select which image is loaded the next time the unit reboots.
Firmware Images: ActiveImage:2
Info Select ()
The modem can store two complete firmware images. The read-only top line shows the active
firmware image. On the bottom line, use the arrow keys to select a parameter. Press
ENTER.
6.2.6.8.1 (Utility: Firmware Images) Info
Firmware Information: ActiveImage:2
Boot-ROM Image#1 Image#2 ()
The read-only top line shows the active firmware image. On the bottom line, use the arrow
keys to select Boot-ROM, Image#1, or Image#2. Press ENTER to view the selected firmware
information. Per the following example:
Image #1 Bulk: 03/22/13
FW-0020627- 1.1.1 ()
Use the arrow keys to scroll through information of all the constituent firmware blocks
that make up the bulk. Press ENTER or CLEAR to return to the previous menu.
