Part Number MN/MBT4000.IOM - Revision 0 MBT-4000B Multi-Band Transceiver System Installation and Operation Manual IMPORTANT NOTE: The in

Multi-Band Transceiver System Revision 0 Preface MN/MBT4000B.IOM viii EMC COMPLIANCE This is a Class A product. In a domestic environment, it may c

Multi-Band Transceiver System Revision 0 Preface MN/MBT4000B.IOM ix SAFETY COMPLIANCE EN 60950 Applicable testing is routinely performed as a cond

Multi-Band Transceiver System Revision 0 Preface MN/MBT4000B.IOM x WARRANTY POLICY This Comtech EF Data product is warranted against defects in mat

1-1 Chapter 1. Introduction Figure 1-1. MBT-4000B Outdoor Multi-Band RF Transceiver 1.1 OVERVIEW This manual provides instructions on the installati

Multi-Band Transceiver System Revision 0 Introduction 1-2 BIASTBUC X (SLOT 1)1:1 MBT SUBSYSTEMNote: L-Band, 10 MHz, DC Bias. TO SSPA X To L-Ba

Multi-Band Transceiver System Revision 0 Introduction MN/MBT4000B.IOM 1-3 1.3 SPECIFICATIONS 1.3.1 SUMMARY OF SPECIFICATIONS BUC-4000 ODU Characte

Multi-Band Transceiver System Revision 0 Introduction MN/MBT4000B.IOM 1-4 1.3.2 DIMENSIONAL ENVELOPE Figure 1-3. MBT-4000B Dimensional Envelope

Multi-Band Transceiver System Revision 0 Introduction MN/MBT4000B.IOM 1-5 1.3 SYSTEM OVERVIEW The transceiver is constructed in a modular configura

Multi-Band Transceiver System Revision 0 Introduction MN/MBT4000B.IOM 1-6 NOTES:

2- 1Chapter 2. Installation 2.1 UNPACKING AND INSPECTION In

Multi-Band Transceiver System Revision 0 Installation MN/MBT4000B.IOM 2-2 2.2.1 COMM (J2) PIN CONNECTIONS Table 2-2. COMM (J2) Pin Connections Pin

Multi-Band Transceiver System Revision 0 Installation MN/MBT4000B.IOM 2-3 2.2.2 IF SWITCH (J4) PIN CONNECTIONS Table 2-3. IF Switch (J4) Pin Connect

Multi-Band Transceiver System Revision 0 Installation MN/MBT4000B.IOM 2-4 2.2.4 AUX COMM 1 (J9) PIN CONNECTIONS Table 2-5. Aux Comm 1 (J9) Pin Conn

Multi-Band Transceiver System Revision 0 Installation MN/MBT4000B.IOM 2-5 2.2.5 RF SWITCH (J10) PIN CONNECTIONS Table 2-6. RF Switch (J10) Pin Conne

Multi-Band Transceiver System Revision 0 Installation MN/MBT4000B.IOM 2-6 NOTES:

3-1 Chapter 3. System Operation 3.1 DESCRIPTION The MBT 4000B supports LNBs for receive down conversion. It outputs +17VDC nominal and 10 MHz on t

Multi-Band Transceiver System Revision 0 System Operation MN/MBT4000B.IOM 3-2 3.2 BLOCK UP CONVERTER (BUC-4000) The BUC-4000 translates an L-Band ca

3-3 Multi-Band Transceiver System Revision 0 System Operation

Multi-Band Transceiver System Revision 0 System Operation MN/MBT4000B.IOM 3-4 3.3.2 KU-BAND Table 3-2. For Ku-Band: LO and MIX Information for De

4-1 Chapter 4. Redundant Configuration 4.1 General The MBT-4000B is designed to operate in both stand-alone and redundant configurations. Every MBT-

Copyright © 2006Comtech EF Data, 2005. All rights reserved. Printed in the USA. Comtech EF Data, 2114 West 7th Street, Tempe, Arizona 85281 USA, 480 3

Multi-Band Transceiver System Revision 0 Redundant Configuration MN/MBT4000B.IOM 4-2 4.2 Dual Base (Chain) Redundancy Operation Refer to Figure 4

Multi-Band Transceiver System Revision 0 Redundant Configuration MN/MBT4000B.IOM 4-3 For a switchover to occur: • Both MBT-4000B base units must

Multi-Band Transceiver System Revision 0 Redundant Configuration MN/MBT4000B.IOM 4-4 The following commands and rules configure operation of this

Multi-Band Transceiver System Revision 0 Redundant Configuration MN/MBT4000B.IOM 4-5 4.7 Redundany Systems Check Step Procedure 1 Set up two MBT

Multi-Band Transceiver System Revision 0 Redundant Configuration MN/MBT4000B.IOM 4-6 Step Procedure 14 Verify that both LEDs on MBT A are solid

Multi-Band Transceiver System Revision 0 Redundant Configuration MN/MBT4000B.IOM 4-7 Step Procedure 33 Enable external fault monitoring by sendin

Multi-Band Transceiver System Revision 0 Redundant Configuration MN/MBT4000B.IOM 4-8 This page is intentionally left blank.

A–1 Appendix A. Remote Control This section describes the protocol and message command set for remote monitor and control of the MBT 4000B. The

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A–2 RS-485 (full duplex) summary: Two differential pairs one pair for co

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A–3 A.4 PACKET STRUCTURE Controller-to-Target: Start of Packet Target Ad

ii CUSTOMER SUPPORT Contact the Comtech EF Data Customer Support Department for:  Product support or training  Information on upgrading or return

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A–4 The format of the response will be: >0412A1/MUT={CR}{LF} Sub-devic

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A–5 2. From Target-to-Controller, the only permitted values are: = (ASCII

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A–6 A.4.5 MESSAGE ARGUMENTS Arguments are not required for all messages. Ar

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A–7 A.5 REMOTE COMMANDS A AFR, A-9 ATT, A-9 E EAM, A-15 EOM, A-24 L LC

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A–8 This page is intentionally left blank.

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM 9 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-10 Parameter Type Command (Instruction Code and Qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-11 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-12 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-13 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

iiiTable of Contents CHAPTER 1. INTRODUCTION ... 1–1 1.1 Overview ...

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-14 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-15 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-16 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-17 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-18 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-19 Bias Tee Mute State MSP=x MBT 1 byte, value of 0,1 Command or Query. M

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-20 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-21 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-22 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-23 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Preface MN/MBT4000B.IOM iv CHAPTER 4. REDUNDANT CONFIGURATION ...

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-24 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-25 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-26 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-27 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-28 Parameter Type Command (Instruction Code and qualifier) Valid on MBT,

Multi-Band Transceiver System Revision 0 Remote Command MN/MBT4000B.IOM A-29 NOTES:

B-1 Appendix B. Faults/Events There are three types of Faults/Events that may occur and be recorded in the event log of an MBT-4000B or BUC-4000.

Multi-Band Transceiver System Revision 0 Faults/Events MN/MBT4000B.IOM B-2 Table B-1. MBT-4000B Summary Faults Mnemonic Type Mute Description

Multi-Band Transceiver System Revision 0 Faults/Events MN/MBT4000B.IOM B-3 Table B-4. BUC-4000 Summary Faults Mnemonic Type Description 15V S

Multi-Band Transceiver System Revision 0 Faults/Events MN/MBT4000B.IOM B-4 This page is intentionally left blank.

Multi-Band Transceiver System Revision 0 Preface MN/MBT4000B.IOM v Figures Figure 1-1. MBT-4000B Outdoor Multi-Band RF Transceiver ...

METRIC CONVERSIONS Units of Length Unit Centimeter Inch Foot Yard Mile Meter Kilometer Millimeter 1 centimeter — 0.3937 0.03281

2114 WEST 7TH STREET TEMPE ARIZONA 85281 USA 480 • 333 • 2200 PHONE 480 • 333 • 2161 FAX

Multi-Band Transceiver System Revision 0 Preface MN/MBT4000B.IOM vi This page is intentionally left blank.

Multi-Band Transceiver System Revision 0 Preface MN/MBT4000B.IOM vii ABOUT THIS MANUAL This manual provides installation and operation information
