Part Number MN/UB54.IOM Revision 1 UB-54Breakout PanelInstallation and Operation Manual

Introduction UB-54 Breakout Panel 1–2 Rev. 1 • An auxiliary circuit connector to provide easy access to 8-channel Mux Master Clock inputs, Demod and

UB-54 Breakout Panel Introduction Rev. 1 1–3 This page is intentionally left blank.

Introduction UB-54 Breakout Panel 1–4 Rev. 1 TRIB 3 TRIB 4E7E8E9E10E11E12815714613512411310291J3DSB15FRPCTH815714613512411310291J4DSB15FRPCTHTRIB 1

UB-54 Breakout Panel Introduction Rev. 1 1–5 AUXE22E23E24815714613512411310291J9DSB15FRPCTHTRIB 6 TRIB 7 TRIB 8E13E14E15E16E17E18E19E20E21815714613

Introduction UB-54 Breakout Panel 1–6 Rev. 1 This page is intentionally left blank.

Rev. 1 2–1 2Chapter 2. INSTALLATION This chapter provides unpacking and installation instructions, and a description of external connections. 2.1

Installation UB-54 Breakout Panel 2–2 Rev. 1 2.2 Installation The breakout panel arrives fully assembled from the factory. Install the breakout pan

UB-54 Breakout Panel Installation Rev. 1 2–3 UB-54SDM-300 W/INTEGRATED8 CHANNEL MULTIPLEXERTRIB 1 DATA TRIB 2 DATA TRIB 3 DATA TRIB 4 DATA TRIB 5 DA

Installation UB-54 Breakout Panel 2–4 Rev. 1 2.3 External Connections and Circuit Assignments 2.3.1 Front Panel Connectors The location of the co

UB-54 Breakout Panel Installation Rev. 1 2–5 2.3.2 Circuit Assignments for Front Panel Connectors Refer to Table 2-2 through 2-10 for circuit assig

Part Number MN/UB54.IOM Revision 1

Installation UB-54 Breakout Panel 2–6 Rev. 1 Table 2-4. Tributary #3 Circuit Assignments (J3) TRIB 3 J3 MUX DEMUX Pin # Circuit Description Cir

UB-54 Breakout Panel Installation Rev. 1 2–7 Table 2-7. Tributary #6 Circuit Assignments (J6) TRIB 6 J6 MUX DEMUX Pin # Circuit Description Cir

Installation UB-54 Breakout Panel 2–8 Rev. 1 Table 2-10. Auxiliary Circuit Pin Assignments (J9) AUX J9 MUX DEMUX Pin # Circuit Description Circ

UB-54 Breakout Panel Installation Rev. 1 2–9 2.3.3 Rear Panel Connectors The location of the connectors are shown in Figure 2-1. Refer to Table 2-1

Installation UB-54 Breakout Panel 2–10 Rev. 1 Table 2-12. MUX Data Pin Assignments (J10) J10 MUX Data Pin # Circuit Description Pin # Circuit

UB-54 Breakout Panel Installation Rev. 1 2–11 Table 2-13. Receive Aggregate Pin Assignments (J11) J11 RX Aggregate Pin # Circuit Description 1

Installation UB-54 Breakout Panel 2–12 Rev. 1 Table 2-14. DEMUX T1 Through T4 Pin Assignments (J12) J12 DEMUX T1 through T4 Pin # Circuit Descri

UB-54 Breakout Panel Installation Rev. 1 2–13 Table 2-15. DEMUX T5 Through T8 Pin Assignments (J13) J13 DEMUX T5 through T8 PIN # Circuit Descri
